Saturday, May 08, 2010

New Equalizer Designs added to our Product Line

We've released some new equalizer designs in the past few months:
Part Number Start Freq (GHz) Stop Freq (GHz) Full Band Slope
REQ-M02-F0.5-18.0-S10.5 0.5 18.0 10.5
REQ-M02-F0.5-18.0-S9.0 0.5 18.0 9.0
REQ-M02-F0.5-18.0-S17.5 0.5 18.0 17.5
REQ-M02-F1.0-8.0-S3.0 1.0 8.0 3.0
REQ-M02-F1.0-8.0-S2.0 1.0 8.0 2.0
REQ-M02-F8.0-18.0-S3.0 8.0 18.0 3.0
REQ-M02-F0.1-1.0-S38.0 0.1 1.0 38.0
REQ-M02-F0.1-1.0-S15 0.1 1.0 15.0

For more information and test results, visit or "Equalizers on Demand" WWW page. If you don't see a design that fits your needs, please call us and we'll try to develop a design that meets your requirements. Thanks for all your support, equalizer users!

38 dB slope equalizer
Posted by Bob Wood at 11:42 PM
Edited on: Monday, October 07, 2013 9:52 PM
Categories: 20 Hardware Products-Current

Test Station Delivered to NAVSEA NSWC

We delivered a Test Station to NAVSEA Naval Surface Warfare Center (NSWC) in Crane, Indiana. The Test Station contains many state of the art features, including:

  • The latest Agilent Network Analyzer (PNA-X Series)
  • A 10-port Extension for measuring multi-port S-parameters
  • An R. A. Wood Associates custom-designed RF Load Box/Chassis for testing high power RF devices
  • Rack mount computer, keyboard, and monitor with digital I/O, GPIB interfaces
  • A PXI chassis with fiber optic interface, digital I/O, serial interfaces, temperature monitors, and GPIB interfaces
  • LabVIEW Software utilities to support setting up the Network Analyzer, retrieving S-parameters from the Network Analyzer, controlling the RF Load Box, and controlling other measurement equipment in the Test Station

This was a very exciting project, and we really enjoyed working with our customer on this program. The complete project was delivered within 7 months of the order being placed. Great job everybody!


Posted by Bob Wood at 3:48 PM
Edited on: Wednesday, October 09, 2013 12:05 PM
Categories: 10 QuickNews, 20 Hardware Products-Current, 30 LabVIEW Projects-Current, 40 Engineering Consulting Services-Current
